Merge lake bathymetry raster with a DEM raster

Usage

merge_bathy_dem(
  shoreline,
  bathy_raster,
  dem_raster,
  transform_shoreline = TRUE,
  catchment = NULL,
  crop_dem_to_catchment = TRUE
)

Arguments

shoreline: sf object of lake shoreline.
bathy_raster: SpatRaster object with the bathymetry data.
dem_raster: SpatRaster object with the DEM data.
transform_shoreline: logical. If TRUE, the shoreline will be transformed to match the CRS of the DEM raster.
catchment: sf object of the catchment boundary. If provided, the DEM raster will be cropped to the catchment boundary.
crop_dem_to_catchment: logical. If TRUE, the DEM raster will be cropped to the catchment boundary. Requires catchment to be provided.

Value

SpatRaster object with the merged bathymetry and DEM data.

Examples

shoreline <- readRDS(system.file("extdata/rotoma_shoreline.rds",
package = "bathytools"))
catchment <- readRDS(system.file("extdata/rotoma_catchment.rds",
                                 package = "bathytools"))
point_data <- readRDS(system.file("extdata/depth_points.rds",
package = "bathytools"))
bathy_raster <- rasterise_bathy(shoreline = shoreline,
point_data = point_data, crs = 2193)
#> Generating depth points... [2024-11-13 23:09:05]
#> Finished! [2024-11-13 23:09:05]
#> Interpolating to raster... [2024-11-13 23:09:05]
#> Adjusting depths >= 0 to  -0.82 m
#> Finished! [2024-11-13 23:09:22]

dem_raster <- terra::rast(system.file("extdata/dem_32m.tif",
package = "bathytools"))
dem_bath <- merge_bathy_dem(shoreline = shoreline, bathy_raster = bathy_raster,
dem_raster = dem_raster, catchment = catchment)
#> Warning: Resolutions of bathy_raster [2, 2] and dem_raster [32, 32] do notmatch. Resampling bathy_raster to match dem_raster
#> Lake surface elevation from DEM: 313.3 m
